Features

• Integrated Windows software for collecting measurement data from Ritter products
• Multi-core processor support
• Windows software for collecting gas volume and flow rate data from up to 18 Ritter Gas Meters to a PC USB port
• Displays measurement data in graphical and tabular form in real time
• Normalization of measurement data by the following methods:
  1. Temperature
  2. Pressure
  3. Humidity
• Measurement data is stored on both the SD card (built into the Signal Interface Module »SIM«) and the PC
• Data acquisition is possible even when the main power supply fails
• Export of stored data to Microsoft Excel spreadsheets

Please note: »RIGAMO« can only be started once at a time on a single PC. Bidirectional recognition of measurement drum rotation is not supported in Pulse Generator V4.01. The Signal Interface Module »SIM« required for data acquisition is not approved for use in explosion-proof areas!

Gas Volume Measurement

• Collection of gas volume and flow rate data from up to 18 Ritter Gas Meters
• Gas temperature measurement for recalculation to standard temperature (normalization) Please note: In the current version of the Signal Interface Module »SIM«, only a single temperature probe can be connected to one »SIM« device.
• Atmospheric pressure measurement for recalculation to standard pressure (normalization)
• Humidity compensation
• Automatic correction of measurement data based on individual calibration curves: »Dynamic correction of measurement errors« (MilliGascounter only)

Biogas Batch Fermentation System »BBFS« Application

• Temperature control of the heating oven
• Speed control of the stirring unit including fermentation bottle (interval mode)
• Real-time CO₂ absorption status for up to 18 CO₂ absorption bottles (with »CO₂ Absorption System«, an optional accessory of the Biogas Batch Fermentation System »BBFS«):
• Display of the current CO₂ absorption capacity of each absorption bottle
• Display of the remaining CO₂ absorption volume of each absorption bottle
• Alarm function for each absorption bottle when CO₂ absorption capacity falls below a freely selectable level

Interface: Configuration Window

-Area 1: Consecutive number of input ports / channels
- Area 2: Checkboxes for selection / deselection of single channels
- Area 3: Assignment of Gas Meter type to each port
- Area 4: Selection of Pulse Generator type for each Gas Meter
- Area 5: Selection of calibration data file for each Gas Meter (MilliGascounter only)
- Area 6: Input of time interval value for saving of measurement data to the PC
- Area 7: Selection of time interval unit for saving of measurement data
- Area 8: Selection of mode for termination of data acquisition
- Area 9: Input of value for termination of data acquisition
- Area 10: Optional input of user / identifier for a test run
- Area 11: Optional input of description or comment for a test run
- Area 12: Directory path for measurement data
- Area 13: Checkbox for selection / deselection of all ports
- Area 14: Master line for simultaneous input / deletion of parameters in marked channels
- Area 15: Saves entered parameters and closes the Configuration Window
- Area 16: Closes the Configuration Window without saving entered parameters

Interface: Recording Window

- Area 1: Display of port status
- Area 2: Tabular display of data for respective ports in real time
- Area 3: Checkboxes for displaying or hiding of graphs
- Area 4: Magnification tools for diagram area
- Area 5: Legend for graphs (gas volume and flow rate)
- Area 6: Diagram area for gas volume and flow rate
- Area 7: Selection / deselection of all ports
- Area 8: Start / Stop of data acquisition
- Area 9: Closes the Recording Window
- Area 10: Indication of gas temperature
Activation / deactivation of temperature normalisation
- Area 11: Indication of atmospheric pressure
Activation / deactivation of pressure normalisation

Configuration Example

ASchematic of a completed configuration of RITTER Gas Meter, Signal Interface Module (»SIM«), PC and RIGAMO
(Example for connection of 4 gas meters)
